FLEX-8400M Signature Series SDR Transceiver

FlexRadio Systems

SKU: FLEX-8400M

View resources

0 reviews

MSRP: $3,649.00 $3,649.00

MSRP:

Place your refundable deposit now!

FLEX-8400M Extended Warranty + $699

Rack Mount for FLEX-6400/8400(M) and FLEX-6600/8600(M) + $99

You must be logged in to create a wish list
Log in
Register

0% APR financing available for 6 months *

As low as $168.36 / month ** Select Bread Financing at checkout. Details Purchasing programs International resellers

The FLEX-8400M offers the latest direct sampling SDR technology with a high-resolution display and ergonomic controls.

Place your deposit now!

Supporting Adaptive Predistortion

The FLEX-8400M integrates all FLEX-8400 capabilities with a stunning 8-inch 1920×1200 IPS WUXGA touchscreen display and ergonomic controls to deliver a high-performance Software Defined Radio (SDR) with a traditional radio interface.

It delivers unmatched band awareness from an integrated display while providing an external connection to monitor compatible 1900×1200 resolution on a monitor for maximum spectral visibility.

Influenced by top contest/DX operators, its symmetrical and independent dual VFO controls are strategically placed to provide maximum productivity for all types of operation. It’s completely self-contained so just plug it in and operate – no PC, network or learning curve required.

With a PC, laptop, or Mac client you can utilize up to two 7 MHz spectrum/waterfall displays and independent receivers to revolutionize your view of the bands. Its two receivers can be placed simultaneously on any band and mode with instant QSY between VFOs. Digital mode operation is a dream with no sound cards, cables, or boxes needed.

FlexRadio’s industry-leading SmartSDR^TM software offers compatibility across the entire FLEX-8000 Signature Series family to deliver continuous leveraged software enhancement. And you can use the latest SmartLink^TM technology to access your radio virtually anywhere from any SmartSDR compatible client with only a login and password – even your iPhone.

View FLEX-8400 without integrated display

*Mac OSX SmartSDR and iOS SmartSDR clients are provided by third-party vendors

Features

100W PEP HF-6m operation
All modes/all bands
Integrated Remote Operation with Maestro, PC/Laptop, Mac, IPad® or iPhone®
2 Independent Band / Mode Receivers
Full Duplex Cross-Band Operation
Transverter Port
Receive-Only Antenna Port
Direct Sampling SDR 122.88Msps – 16 bit
115 dB 2kHz RMDR
>155 dB Dynamic Range
10 MHz Reference Input
Optional Integrated Antenna Tuner, Range 3:1 SWR
Optional GPSDO for ultra high frequency precision and accuracy
Optional MARS/CAP/SHARES TX Expansion Module

All-in-One SDR includes all the features of the FLEX-8400 plus

Spectacular 8-inch, 1920 x 1200 IPS Integrated Display
Touch Tune, Zoom, Pan Controls at Your Fingertips
Ergonomically Optimized Controls with Full Dual VFP
Up to 7MHz Spectrum/Waterfall Bandwidth
Real-time Spectrum / Waterfall
External Display Output – Full 1920 x 1200 Resolution
Internal Speaker

Full Specifications

Specs

Weight: 256 oz
Width: 18 in
Depth: 19 in
Height: 12 in

Receiver

Independent Band/Mode Receivers (Max): 2
½ kHz Reciprocal Mixing Dynamic Range (RMDR): 110/115 dB
ADC Bits/Sampling Rate: 16/122.88 Msps
Frequency Coverage: 30 kHz-54 MHz
Amateur Band Preselectors: 3rd Order
Cable-less Digital Audio (DAX/DAX IQ) Channels: 2/2
Receive Only Ports (Base/Including XVTR Port): ½
Full Duplex RX/TX Operation

Spectrum / Waterfall

Integrated Touch Panel Display Size Diagonal: 8-inch (8400M)
Integrated Display Resolution: 1920 x 1200
External Display Resolution/Connection: 1920×1200 / HDMI (8400M)
Spectrum / Waterfall Displays (Max): 2
Spectrum /Waterfall BW (Min/Max): 5 kHz to 7 MHz
Spectrum Dynamic Range (Max Zoom In): >145 dB
Spectrum Resolution Bandwidth (Min): 5.58 Hz/px

Transmitter

160m-6m Transmitter Output: 1-100W (25W AM)
Harmonic Suppression (Typ): <60 dBc
Transverter Ports: 1
Transverter Frequency Coverage/Power: 100kHz – 54 MHz/0 to +10 dBm
Optional Integrated Automatic Antenna Tuner Range: 3:1 SWR
Optional Continuous MARS/CAP Coverage with Extended Transmit Filter

General

Modes¹ SSB, CW, AM, SAM, FM, RTTY, DIGITAL
Integrated Remote Operation (SmartLink)
Maestro, PC, Mac, iPhone® and iPad® Client Options
Frequency Stability (0⁰C – 50⁰C) 0.5ppm (TCXO)
Optional GPS Disciplined Oscillator (5 x 10-12 Over 24 Hours)
External 10MHz Reference Input
Power Supply Requirements 13.8 VDC +/- 15% (14 VDC Nominal)
Dimensions 6.74”H (17.1 cm) x 14”W (35.6 cm) x 13.25”D (33.7 cm)

1. RTTY and other digital modes use 3rd party software over DAX channels.

Ancillary information

Simply Beautiful

No PC required to operate the FLEX-8400M
8 inch 1920 x 1200 IPS Display
Up to two independent receivers
Up to two 7MHz spectrum displays
Optimized workflow
Ergonomically spaced / single-function controls

Plug & Play Remote ²

No complex setup required
Operate anywhere, any time
Use a Maestro, Mac, iPad, iPhone or Laptop
Across the country or across the world
Anywhere, Anytime, From Any of These Devices:
- With SmartLink and a FLEX-8400M, you can operate your radio from almost anywhere! Just take an iPhone, iPad, Laptop, or Maestro with you and instantly connect to your radio with virtually no setup required.

Best in Class Performance

115 db RMDR
No listening fatigue
Ultra-low phase noise
Full Break-in QSK CW
Brick Wall Filters
Stunning transmit audio

Backed by an Amazing Suite of Software

SmartSDR for the M Model Radio
SmartSDR for Windows
SmartSDR for Mac³
SmartSDR for iOS³
SmartSDR CAT
DAX

1 – A PC is required for use of 3rd party software such as loggers and digital mode programs.
2 – SmartLink Remote requires SmartSDR v2.x license or higher. Requires and Internet connection.
3 – SmartSDR for Mac and SmartSDR for iOS are optional, 3rd party software for pay options.
