| MSRP | $6,199.00 | $7,349.00 | $8,599.00 | $9,599.00 |
| Transmitter Power | 1–500W HF, 1–200W 6m | 1–500W HF, 1–200W 6m | 1–500W HF, 1–200W 6m | 1–500W HF, 1–200W 6m |
| Efficiency (Peak) | Up to 80% | Up to 80% | Up to 80% | Up to 80% |
| Spectral Capture Units (SCUs) | 1 | 1 | 2 | 2 |
| Slice Receivers / Panadapters | 2/2 | 2/2 | 4/4 | 4/4 |
| RX Antenna Ports | 1 | 1 | 2 | 2 |
| Transverter Ports (0 – +10dBm) |
1 | 1 | 2 | 2 |
| Frequency Coverage | 30kHz–54MHz | 30kHz–54MHz | 30kHz–54MHz | 30kHz–54MHz |
| Full Duplex |  |
|
|
|
| Display | x | 8″ 1920×1200 IPS Touchscreen | x | 8″ 1920×1200 IPS Touchscreen |
| Maestro Front Panel | x | |
x | |
| Integrated HDMI Output | |
|
|
|
| SmartSignal™ (Adaptive | |
|
|
|
| CESSB (RF Compression) | |
|
|
|
| MultiFlex™ (Dual Client Support) | |
|
|
|
| Integrated Tuner | |
|
|
|
| Integrated Power Supply | |
|
|
|
| Remote Operation (SmartLink™) | |
|
|
|
| External Display Support (HDMI®) | x | |
x | |
| GNSS / GPSDO Support | ✓ / Optional | ✓ / Optional | ✓ / Optional | ✓ / Optional |
| SO2R Ready | x | x | |
|
| Power Input | 80–264VAC | 80–264VAC | 80–264VAC | 80–264VAC |
| Dimensions (H × W × D) | 6.74″ × 14″ × 13.25″ | 6.74″ × 14″ × 13.25″ | 6.74″ × 14″ × 13.25″ | 6.74″ × 14″ × 13.25″ |
